Item

LE16

EPON

IEEE 802.3ah standard

Support standard OAM and extended OAM

ONU identifier authentication: MAC/LOID

High splitting ratio, each PON port supports 64*ONUs Maximum transmission distance 20KM

Support uplink FEC, downlink FEC(forward error correction)

Bandwidth allocation mechanism

5 T-CONT bandwidths

Static bandwidth allocation

Dynamic bandwidth allocation

MAC

MAC Black Hole

Port MAC Limit

VLAN

4K VLAN entries

Port-based/MAC-based/IP subnet-based VLAN

Port-based QinQ and Selective QinQ(Stack VLAN)

VLAN Swap and VLAN Remark and VLAN Translate

Based on ONU service flow VLAN add, delete, replace

L2 Protocol

STP, RSTP, MSTP

Port

Bi-directional bandwidth control

Static link aggregation and LACP(Link Aggregation Control Protocol)

Port mirroring and traffic mirroring

L3 Protocol

OSPF, IS-IS, BGP

User Security

Anti-ARP spoofing

Prevent ARP flooding

IP source protection creates IP VLAN+MAC+port binding

Port isolation

MAC address binding to port and port MAC address filtering

IEEE 802.1x and AAA/Radius authentication

TACACS+ certification

DHCP anti-attack flooding attack automatic suppression

ONU isolation control

Device security

Anti-DOS attack(such as ARP, Syn flood, Smurf, ICMP attack),ARP detection, worm and Ms-blaster worm attack

SSHv2 Secure Shell

SNMP v3 encrypted management

Security IP login through Telnet

Hierarchical management and password protection of users

Network security

User-based MAC and ARP traffic examination

Restrict ARP traffic of each user and force-out user with abnormal ARP traffic

Dynamic ARP table-based binding

Supports IP+VLAN+MAC+Port binding

L2 to L7 ACL flow filtration mechanism on the 80 bytes of the head of user-defined packet

Port-based broadcast/multicast suppression and auto-shutdown risk port

URPF to prevent IP address counterfeit and attack

DHCP Option82 and PPPOE+upload user’s physical location

Plain-text authentication of OSPF/RIPv2 and MD5 cartography authentication

IPv4

ARP Proxy

DHCP Relay

DHCP Server

Static route

IPv6

ICMPv6

ICMPv6 redirection

DHCPv6

ACLv6

Configured Tunnel

6to4 tunnel

IPv6 and IPv4 Tunnels

ACL

Standard and extended ACL

Time Range ACL

Packet filter providing filtering based on source/destination MAC address, source/destination IP address, port, protocol, VLAN, VLAN range, MAC address range, or invalid frame.

System supports concurrent identification at most 50 service traffic

Support packet filtration of L2～L7 even deep to 80 bytes of IP packet head

QoS

The rate limit of the data packet sending/receiving speed of the port or custom flow. Remarks on the priority of the port or custom flow, and provides 802.1P, DSCP priority and remarks

CAR(Committed Access Rate),Traffic Shaping and flow statistics

Packet mirror and redirection of interface and self-defined flow

Super queue scheduler based on port and self-defined flow. Each port/flow supports 8 priority queues and scheduler of SP,WRR and SP+WRR.

Congestion avoid mechanism, including Tail-Drop and WRED

Multicast

IGMPv1/v2/v3

IGMPv1/v2/v3 Snooping

IGMP Filter

MVR and cross VLAN multicast copy

IGMP Fast leave

IGMP Proxy

MLDv2/MLDv2 Snooping

Loop protection

EAPS and GERP(recover-time<50ms)

Loop back detection

Link protection

FlexLink(recover-time<50ms)

RSTP/MSTP(recover-time<1s)

LACP(recover-time<10ms)

Device protection

Double fault-tolerant backup of host program and configuration files

1+1 power hot backup

Network maintenance

Telnet-based statistics

RFC3176 sFlow

LLDP

802.3ah Ethernet OAM

RFC 3164 BSD syslog Protocol

Ping and Traceroute

Device management

Web management

Console/Telnet, Command-line interface(CLI)

Upgrade via FTP

System configuration with SNMPv1/v2/v3

RMON(Remote Monitoring)

Support SNTP network time protocol

Item

LE16

Switching capacity

128Gbps

Mac Address

64K

Ports

16*PON port,4*10G SFP+,4*GE TX

Power redundancy

Dual power supply. Can be double AC, double DC or AC+DC(optional)

Power supply

AC: Input 85～264V,47～63Hz

DC: Input -36V～-75V

Maximum Power

80W

Outline dimensions (mm) (W*D*H)

440mm*312mm*44mm

Weight

≤5kg

Environmental requirements

Working temperature: -10°C~50°C

Storage temperature:-40°C～85°C

Relative humidity:5%～95%, no condensing
