Forward RF parameters

Bandwidth

MHz

87 ～ 870（1000）

Flatness

Worst

dB

±0.75

Impedance

Ω

75

RF out level

dBmV

Optical power:24±2@ -4dBmW

 Modulation OMI=3.7%

RF reflect loss

Worst

dB

16

RF out test point

-dB

20±0.75

CNR

dBc

＞48 @ –4dBmW Optical power

CTB

dBc

＞70 @ –4dBmWOptical power

CSO

dBc

＞65 @ –4dBmWOptical power

Forward optical parameters

Receiving power

dBm

-8 ～ 0

Power test point

V/mW

+1V/mW

Equivalent noise current

＜4pA /√H

Working wave length

nm

1200～1600

Backward RF parameters

Bandwidth

MHz

5 ~65

Flatness

Worst

± dB

0.75

Impedance

Ω

75

RF reflect loss

Worst

- dB

16

RF input level

dBmV

20

RF test point

-dB

20±0.75

Backward optical parameters

Transmitter  type

IFP

Out power

Standard

dBmW

0

Power test point

V/mW

+1V/mW

Wave length

nm

1310

NPR

dB

20（≥30dB）

General

Operating temperature

℃

- 25～+65

Voltage

VDC

+12 ～ +24

Power consumption

W

4

surge protection

KV

6

RF output stability

dB

±0.75

Connector type

SC/APC
